Name: LJ101 Semi-automatic saddle stitcher
Model: LJ101
Place of origin: Dongguan
Specifications:
Multi heads semi automatic saddle stitching stapler LJ101adopts to binding all
kinds of presswork, such as thin books, periodicals, magazines, advertisements,
instructions, etc. Generally speaking,it uses two nails to bind a book,but at
most it uses four nails to bind a book at the same time,It can finish binding once
no matter they are single page or double-page books.
This machine adopts variable frequency speed go verrning system. Accordingly,
it operates stably and governs the speed conveniently, Besides, this machine
adopts photoelectric eye control and you can select in terleaving or non-
interleaving form to meet distinct needs. After it has the provedure of manual
page lapping, this machine can automatically convey books and automatically
collect books. It possesses following features: simple operation, convenient
maintenance, high stability,large binding range,high production efficiency etc.
This machine has the protecting equipment of lacking of books,It can better
protect binding heads and be operated easily.
The main parameters:
|
Model |
LJ101 |
LJ101Photoelectric type |
|
Binding Size |
89x127-305x450mm |
89x127-305x450mm |
|
Max.Binding Thickness |
4mm |
4mm |
|
Stitching Speed |
15-100 time/ min |
15-100 time/ min |
|
Width of Staple Boot |
13mm |
13mm |
|
Distance of Center of Staple Boot |
45-270mm |
45-270mm |
|
Use of Steel Wire |
25#-26# |
25#-26# |
|
Main Motor |
380V50Hz 0.75kw 1400r/min(Power 220V) |
380V50Hz 0.75kw 1400r/min(Power 220V) |
|
Weight of Machine |
320Kg |
320Kg |
|
Dimensions |
2200x1320x1350mm |
2200x1320x1350mm |
About LiJia Factory:
Established in 2004. Dongguan LiJia Binding Equipment Co., Ltd located in
Chang’an Town, Dongguan city, Guangdong province, China. Which is a leading
professional producing of post-press finishing manufacturer in China, Our main
products are Hardcover Cashing-in machine, book block rounding machine,Book
corner cutting machine, Book block ridging machine, book pressing machine,
Hydraulic book packing machine, paperboard slitter, paperboard
cross cutter and so on.
Since established, Our Company always adhere of “Best service, Best quality”
the core idea. And strive to bring customers the best quality and best service.
The company development and design's product, like Book Block Rounding
Machine, book block ridge machine, hydraulic cutting two horns machine and
other products are domestic initiative, Has been successfully applied for national
patents, was the best cost-effective in the similar products. Also can make to
order as each kind of machine according to the customer’s requirement.
We will continue to be customer oriented, to the best quality and service to win
the trust of customers and work!
